AIR COMPRESSOR
8061SRi10.05 — 8061SRi10
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 98415831 | WATER PUMP WATER PUMP | 1 | |
| 2 | 4842822 | FLAT ENGINE GKT FLAT ENGINE GKT | 1 | |
| 3 | 8016621 | WATER PIPE WATER PIPE | 1 | |
| 4 | 4864082 | BANJO BOLT BANJO BOLT | 1 | |
| 5 | 4858607 | WASHER WASHER | 2 | |
| 6 | 8013358 | PLUG PLUG | 1 | |
| 7 | 98418621 | GASKET GASKET | 1 | |
| 8 | 4772995 | WATER PIPE WATER PIPE | 1 | |
| 9 | 17742887 | RUBBER SLEEVE RUBBER SLEEVE | 1 | |
| 10 | 17764791 | CLIP CLIP | 2 | |
| 11 | 8016520 | WATER PIPE WATER PIPE | 1 | |
| 12 | 8107555 | WATER PIPE WATER PIPE | 1 | |
| 13 | 17764591 | CLIP CLIP | 2 | |
| 14 | 98421371 | AIR HOSE AIR HOSE | 1 | |
| 15 | 15971921 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 16 | 15972321 | HEXAGON BOLT HEXAGON BOLT | 3 | |
| 17 | 17090174 | SPRING WASHER SPRING WASHER | 15 | |
| 18 | 4936741 | CLIP CLIP | 1 | |
| 19 | 4929652 | RETAINER RETAINER | 1 | |
| 20 | 16607524 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 21 | 17094904 | WASHER WASHER | 2 | |
| 22 | 98401723 | HEXAGON BOLT HEXAGON BOLT | 2 | |
| 23 | 16045721 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 24 | 17089474 | SPRING WASHER SPRING WASHER | 1 | |
| 25 | 98419016 | WATER PUMP PULLEY WATER PUMP PULLEY | 1 | |
| 26 | 98454857 | V-BELT V-BELT | 1 | |
| 27 | 4838851 | V-BELT V-BELT | 1 | |
| 28 | 98429847 | BELT TENSIONER BELT TENSIONER | 1 | |
| 29 | 15004021 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 30 | 11227921 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 31 | 17793904 | WASHER WASHER | 2 | |
| 32 | 11288021 | HEXAGON BOLT HEXAGON BOLT | 6 | |
| 33 | 8014973 | PULLEY PULLEY | 1 | |
| 34 | 17038121 | HEXAGON NUT HEXAGON NUT | 1 |
