AIR COMPRESSOR
8061SRi10.05 — 8061SRi10
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 4842719 | SUPPORT SUPPORT | 1 | |
| 2 | 98400800 | BELT TENSIONER BELT TENSIONER | 1 | |
| 3 | 4774408 | PULLEY PULLEY | 1 | |
| 4 | 15004021 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 5 | 17090174 | SPRING WASHER SPRING WASHER | 6 | |
| 6 | 17037821 | HEXAGON NUT HEXAGON NUT | 1 | |
| 7 | 17088474 | WASHER WASHER | 1 | |
| 8 | 15970921 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 9 | 11343821 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 10 | 15888821 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 11 | 16605924 | SCREW SCREW | 3 | |
| 12 | 17089474 | SPRING WASHER SPRING WASHER | 3 |
