INTAKE MANIFOLD
8141i67.01 — 8141i67
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 7301885 | INTAKE ELBOW INTAKE ELBOW | 1 | |
| 2 | 4279436 | INTAKE ELBOW GASK. INTAKE ELBOW GASK. | 4 | |
| 3 | 10263160 | SEAL GASKET SEAL GASKET | 1 | |
| 4 | 16102011 | HEXAGON NUT HEXAGON NUT | 1 | |
| 5 | 7302320 | PIPE SOCKET PIPE SOCKET | 1 | |
| 6 | 13417608 | CLIP CLIP | 2 | |
| 7 | 7302256 | RETAINER RETAINER | 1 | |
| 8 | 11194071 | WASHER WASHER | 1 | |
| 9 | 10902021 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 10 | 7302255 | RUBBER SLEEVE RUBBER SLEEVE | 1 | |
| 11 | 11194371 | SPRING WASHER SPRING WASHER | 1 | |
| 12 | 7302252 | FASTENING BRACKET FASTENING BRACKET | 1 |
