COMPRESSOR AIR CONDITIONING
8149.03.4030 — 8149.03 CNG
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 500327469 | BELT TENSIONER BELT TENSIONER | 1 | |
| 2 | 16586225 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 3 | 16673835 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 4 | 98460578 | ADJUSTING SCREW ADJUSTING SCREW | 1 | |
| 5 | 17037931 | HEXAGON NUT HEXAGON NUT | 1 | |
| 6 | 98429701 | ENGINE BEARINGS ENGINE BEARINGS | 1 | |
| 7 | 16690424 | CYLIND-HEAD SCREW CYLIND-HEAD SCREW | 1 | |
| 8 | 17089474 | SPRING WASHER SPRING WASHER | 1 |
