SEA WATER LINES
8210SM27.10 — 8210SM27
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 8025474 | WATER PIPE WATER PIPE | 1 | |
| 2 | 8024718 | WATER PIPE WATER PIPE | 1 | |
| 3 | 17290281 | O-RING O-RING | 2 | |
| 4 | 16587124 | HEXAGON BOLT HEXAGON BOLT | 8 | |
| 5 | 8024719 | WATER PIPE WATER PIPE | 1 | |
| 6 | 8025314 | WATER PIPE WATER PIPE | 1 | |
| 7 | 17289981 | O-RING O-RING | 3 | |
| 8 | 16609824 | HEXAGON BOLT HEXAGON BOLT | 4 | |
| 9 | 17091074 | WASHER WASHER | 4 | |
| 11 | 17764993 | CLIP CLIP | 6 | |
| 12 | 4865234 | RUBBER SLEEVE RUBBER SLEEVE | 3 | |
| 13 | 8025315 | WATER PIPE WATER PIPE | 1 | |
| 14 | 17289881 | O-RING O-RING | 1 | |
| 15 | 8025321 | WATER PIPE WATER PIPE | 1 | |
| 16 | 17038121 | HEXAGON NUT HEXAGON NUT | 2 | |
| 17 | 8010647 | FLANGE FLANGE | 1 | |
| 18 | 16690624 | CYLIND-HEAD SCREW CYLIND-HEAD SCREW | 4 | |
| 19 | 17101534 | SPRING WASHER SPRING WASHER | 4 | |
| 20 | 16992240 | THREADED PLUG THREADED PLUG | 1 | |
| 21 | 4858607 | WASHER WASHER | 1 | |
| 22 | 8113295 | CLAMP CLAMP | 3 | |
| 23 | 8113296 | CLAMP CLAMP | 3 | |
| 24 | 1366290 | RUBBER PAD RUBBER PAD | 12 | |
| 25 | 16605524 | HEXAGON BOLT HEXAGON BOLT | 3 | |
| 26 | 17089474 | SPRING WASHER SPRING WASHER | 3 | |
| 27 | 17037931 | HEXAGON NUT HEXAGON NUT | 3 | |
| 28 | 8007133 | RETAINER RETAINER | 1 | |
| 29 | 8025372 | RETAINER RETAINER | 1 | |
| 30 | 8025373 | RETAINER RETAINER | 1 | |
| 31 | 16608824 | HEXAGON BOLT HEXAGON BOLT | 2 | |
| 32 | 17090174 | SPRING WASHER SPRING WASHER | 2 | |
| 33 | 12626201 | WASHER WASHER | 4 |
