AIR COMPRESSOR
8210SRE10.00 — 8210SRE10
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 5129478 | OIL PUMP-STEERING OIL PUMP-STEERING | 1 | |
| 2 | 4850986 | FLAT ENGINE GKT FLAT ENGINE GKT | 1 | |
| 3 | 4670953 | PIPE SOCKET PIPE SOCKET | 1 | |
| 4 | 4503785 | WASHER WASHER | 1 | |
| 5 | 14305521 | SCREW SCREW | 2 | |
| 6 | 11197779 | SPRING WASHER SPRING WASHER | 9 | |
| 7 | 10980821 | STUD STUD | 4 | |
| 8 | 8090343 | KIT-HYDRAULIC PUMP KIT-HYDRAULIC PUMP | 1 | |
| 9 | 17281781 | O-RING O-RING | 1 | |
| 10 | 4690715 | PIPE SOCKET PIPE SOCKET | 1 | |
| 11 | 14306621 | SCREW SCREW | 2 | |
| 12 | 11198079 | SPRING WASHER SPRING WASHER | 2 | |
| 13 | 11197779 | SPRING WASHER SPRING WASHER | 4 | |
| 14 | 15896211 | HEXAGON NUT HEXAGON NUT | 4 |
