WATER LINES
8210SRi40.00 — 8210SRi40
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 4863948 | FLAT ENGINE GKT FLAT ENGINE GKT | 1 | |
| 2 | 4872744 | COVER COVER | 1 | |
| 3 | 4858609 | WASHER WASHER | 1 | |
| 4 | 16992411 | THREADED PLUG THREADED PLUG | 1 | |
| 5 | 16605734 | HEXAGON BOLT HEXAGON BOLT | 5 | |
| 6 | 17089474 | SPRING WASHER SPRING WASHER | 11 | |
| 7 | 4651305 | INTAKE ELBOW INTAKE ELBOW | 1 | |
| 8 | 4830268 | FASTENING BRACKET FASTENING BRACKET | 1 | |
| 9 | 1365519 | FLANGE FLANGE | 1 | |
| 10 | 4640545 | CLIP CLIP | 1 | |
| 11 | 8028472 | WATER PIPE WATER PIPE | 1 | |
| 12 | 4863951 | FLAT ENGINE GKT FLAT ENGINE GKT | 3 | |
| 13 | 4863974 | FLAT ENGINE GKT FLAT ENGINE GKT | 1 | |
| 14 | 17089574 | WASHER WASHER | 1 | |
| 15 | 16605624 | HEXAGON BOLT HEXAGON BOLT | 6 | |
| 16 | 98437153 | WATER HOSE WATER HOSE | 1 | |
| 17 | 17764892 | PIPE CLIP PIPE CLIP | 6 | |
| 18 | 4863960 | WATER HOSE WATER HOSE | 1 | |
| 19 | 4709713 | WATER PIPE WATER PIPE | 1 | |
| 20 | 4565875 | RUBBER PAD RUBBER PAD | 3 |
