FRESH WATER - SEA WATER HEAT EXCHANGER
8281SRM44.10 — 8281SRM44
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 8106667 | SUPPORT SUPPORT | 1 | |
| 2 | 8106666 | SUPPORT SUPPORT | 1 | |
| 3 | 15972621 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 4 | 8106665 | SUPPORT SUPPORT | 1 | |
| 5 | 16610124 | HEXAGON BOLT HEXAGON BOLT | 4 | |
| 6 | 8110946 | RETAINER RETAINER | 1 | |
| 7 | 17091074 | WASHER WASHER | 4 | |
| 8 | 16605524 | HEXAGON BOLT HEXAGON BOLT | 3 | |
| 9 | 17090174 | SPRING WASHER SPRING WASHER | 7 | |
| 10 | 15888721 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 11 | 15004021 | HEXAGON BOLT HEXAGON BOLT | 2 | |
| 12 | 15972021 | HEXAGON BOLT HEXAGON BOLT | 3 | |
| 13 | 17089774 | SPRING WASHER SPRING WASHER | 3 | |
| 14 | 17087993 | CLIP CLIP | 1 | |
| 15 | 17723081 | WATER HOSE WATER HOSE | 1 | |
| 16 | 17316590 | PIPE CLIP PIPE CLIP | 1 |
