THERMO-STARTER
F3BE0681M*B722 — CURSOR 13 - EURO 3
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 99449300 | RELAY RELAY | 1 | |
| 2 | 99437042 | RESISTOR RESISTOR | 1 | |
| 3 | 504026624 | FLAT ENGINE GKT FLAT ENGINE GKT | 1 | |
| 4 | 10450990 | PIPE CLIP PIPE CLIP | 2 | |
| 5 | 41207689 | SUPPORT SUPPORT | 1 | |
| 6 | 99455033 | CLIP CLIP | 1 | |
| 7 | 16592225 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 8 | 16586225 | HEXAGON BOLT HEXAGON BOLT | 2 | |
| 9 | 16585625 | HEXAGON BOLT HEXAGON BOLT | 2 | |
| 10 | 16597925 | HEXAGON BOLT HEXAGON BOLT | 2 | |
| 11 | 17044625 | HEXAGON NUT HEXAGON NUT | 1 | |
| 12 | 16750235 | HEXAGON NUT HEXAGON NUT | 1 | |
| 13 | 504119997 | WIRE/CABLE WIRE/CABLE | 2 | |
| 14 | 504206835 | WIRE/CABLE WIRE/CABLE | 1 | |
| 15 | 41223062 | SUPPORT SUPPORT | 1 |
