WATER LINES
F2BE0681A*BC13 — CURSOR 8 - EURO 3
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 41212774 | LINE LINE | 1 | |
| 2 | 41205053 | SUPPORT SUPPORT | 1 | |
| 3 | 41204234 | BRACKET BRACKET | 1 | |
| 4 | 41212705 | SUPPORT SUPPORT | 4 | |
| 5 | 16750225 | HEXAGON NUT HEXAGON NUT | 8 | |
| 6 | 16673735 | HEXAGON BOLT HEXAGON BOLT | 7 | |
| 7 | 16586625 | HEXAGON BOLT HEXAGON BOLT | 4 | |
| 8 | 41202595 | FASTENING BRACKET FASTENING BRACKET | 4 | |
| 9 | 61599713 | THREADED UNION THREADED UNION | 1 | |
| 10 | 16508560 | WASHER WASHER | 1 |
