OIL DIPSTICK PIPE
C78ENTE20.00 — CURSOR 8 - TIER 2
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 504046522 | OIL FILLER PIPE OIL FILLER PIPE | 1 | |
| 2 | 17281881 | O-RING O-RING | 1 | |
| 3 | 4895037 | PLUG PLUG | 1 | |
| 4 | 16597225 | HEXAGON BOLT HEXAGON BOLT | 1 |
C78ENTE20.00 — CURSOR 8 - TIER 2
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 504046522 | OIL FILLER PIPE OIL FILLER PIPE | 1 | |
| 2 | 17281881 | O-RING O-RING | 1 | |
| 3 | 4895037 | PLUG PLUG | 1 | |
| 4 | 16597225 | HEXAGON BOLT HEXAGON BOLT | 1 |
