AIR CLEANER
C78ENAM12.00 — CURSOR 8
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 8043703 | AIR CLEANER AIR CLEANER | 1 | |
| 2 | 16607524 | HEXAGON BOLT HEXAGON BOLT | 4 | |
| 3 | 17090274 | WASHER WASHER | 4 | |
| 4 | 4856492 | THREADED UNION THREADED UNION | 1 | |
| 5 | 12173090 | CLIP CLIP | 3 | |
| 6 | 18088692 | HOSE CLIP HOSE CLIP | 1 | |
| 7 | 8016336 | OIL HOSE OIL HOSE | 1 | |
| 8 | 8045606 | BREATHER PIPE BREATHER PIPE | 1 | |
| 9 | 98437331 | RUBBER SLEEVE RUBBER SLEEVE | 1 | |
| 10 | 17315390 | FASTENING BRACKET FASTENING BRACKET | 1 | |
| 11 | 8015921 | RETAINER RETAINER | 1 | |
| 12 | 16605524 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 13 | 17089574 | WASHER WASHER | 1 | |
| 14 | 17037925 | HEXAGON NUT HEXAGON NUT | 1 | |
| 15 | 16603677 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 16 | 17088474 | WASHER WASHER | 1 | |
| 17 | 17037821 | HEXAGON NUT HEXAGON NUT | 1 |
