GAS-WATER MIXER WITH STERN OUTLET
C78ENTM50.10 — CURSOR 8
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 8032238 | PIPE PIPE | 1 | |
| 2 | 17764993 | CLIP CLIP | 1 | |
| 3 | 8019908 | HOSE HOSE | 1 | |
| 4 | 4787181 | SUPPORT SUPPORT | 1 | |
| 5 | 17816214 | SPACER SPACER | 1 | |
| 6 | 8113295 | CLAMP CLAMP | 1 | |
| 7 | 8113296 | CLAMP CLAMP | 1 | |
| 8 | 1366290 | RUBBER PAD RUBBER PAD | 4 | |
| 9 | 16605624 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 10 | 17089474 | SPRING WASHER SPRING WASHER | 1 |
