OIL SUMP
C78ENTM55.10 — CURSOR 8
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 8019921 | HAND PUMP HAND PUMP | 1 | |
| 2 | 4928851 | CLIP CLIP | 2 | |
| 3 | 8038195 | OIL LINE OIL LINE | 1 | |
| 4 | 8030711 | PIPE SOCKET PIPE SOCKET | 1 | |
| 5 | 4935200 | PIPE SOCKET PIPE SOCKET | 1 | |
| 6 | 99489022 | SEAL GASKET SEAL GASKET | 2 | |
| 7 | 16500315 | THREADED UNION THREADED UNION | 1 | |
| 8 | 99489019 | WASHER WASHER | 1 | |
| 9 | 4562651 | FASTENING BRACKET FASTENING BRACKET | 1 | |
| 10 | 8038207 | FASTENING BRACKET FASTENING BRACKET | 1 | |
| 11 | 16605424 | SCREW SCREW | 3 | |
| 12 | 17089774 | SPRING WASHER SPRING WASHER | 2 | |
| 13 | 17089474 | SPRING WASHER SPRING WASHER | 2 | |
| 14 | 17037925 | HEXAGON NUT HEXAGON NUT | 1 |
