WATER PUMP DRIVE
F4AE0484C*D103 — NEF 4 electron. - TIER 2
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 16673835 | HEXAGON BOLT HEXAGON BOLT | 2 | |
| 2 | 504028028 | BELT TENSIONER BELT TENSIONER | 1 | |
| 3 | 504065880 | PULLEY PULLEY | 1 | |
| 4 | 8034267 | V-BELT V-BELT | 1 | |
| 5 | 504064340 | SUPPORT SUPPORT | 1 | |
| 6 | 4895292 | HEXAGON BOLT HEXAGON BOLT | 1 |
