FRESH WATER - SEA WATER HEAT EXCHANGER
N60ENTF40.00 — NEF 6 electron.
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 8040642 | SUPPORT SUPPORT | 1 | |
| 2 | 16677735 | HEXAGON BOLT HEXAGON BOLT | 2 | |
| 3 | 8036074 | WATER/SEA WATER HEAT EXCH WATER/SEA WATER HEAT EXCH | 1 | |
| 4 | 17094914 | WASHER WASHER | 3 | |
| 5 | 16045424 | SCREW SCREW | 3 | |
| 6 | 17289681 | O-RING O-RING | 4 | |
| 7 | 8018308 | CONNECTOR SLEEVE CONNECTOR SLEEVE | 2 | |
| 8 | 16600224 | HEXAGON BOLT HEXAGON BOLT | 1 |
