AIR - WATER HEAT EXCHANGER
N67ENTM45.10 — NEF 6 electron.
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 8033578 | AIR/WATER HEAT EXCHANGER AIR/WATER HEAT EXCHANGER | 1 | |
| 2 | 8033847 | SUPPORT SUPPORT | 1 | |
| 3 | 16588225 | HEXAGON BOLT HEXAGON BOLT | 2 | |
| 4 | 16590424 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 5 | 16592225 | HEXAGON BOLT HEXAGON BOLT | 3 | |
| 6 | 16607024 | HEXAGON BOLT HEXAGON BOLT | 4 | |
| 7 | 17094914 | WASHER WASHER | 4 | |
| 8 | 17297081 | O-RING O-RING | 2 | |
| 9 | 16677735 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 10 | 8031755 | WATER PIPE WATER PIPE | 1 |
