AIR - WATER HEAT EXCHANGER
N67MNTF40.01A001 — NEF 6 mechanic. - TIER 2
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 8035937 | AIR/WATER HEAT EXCHANGER AIR/WATER HEAT EXCHANGER | 1 | |
| 2 | 8037181 | SUPPORT SUPPORT | 1 | |
| 3 | 16691224 | CYLIND-HEAD SCREW CYLIND-HEAD SCREW | 2 | |
| 4 | 16586725 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 5 | 16592525 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 6 | 16607024 | HEXAGON BOLT HEXAGON BOLT | 4 | |
| 7 | 17094914 | WASHER WASHER | 4 | |
| 8 | 17297081 | O-RING O-RING | 2 | |
| 9 | 16678135 | HEXAGON BOLT HEXAGON BOLT | 1 | |
| 10 | 8031755 | WATER PIPE WATER PIPE | 1 | |
| 11 | 16673735 | HEXAGON BOLT HEXAGON BOLT | 3 |
