WATER LINES
FVAE2884AB200 — VECTOR 8
Parts List
| # | Part No | Name / Description | Qty | Action |
|---|---|---|---|---|
| 1 | 504208988 | WATER MANIFOLD WATER MANIFOLD | 1 | |
| 2 | 504208989 | WATER MANIFOLD WATER MANIFOLD | 1 | |
| 3 | 504044298 | WATER PIPE WATER PIPE | 1 | |
| 4 | 504049041 | INTAKE ELBOW GASK. INTAKE ELBOW GASK. | 2 | |
| 5 | 504044300 | CONNECTION PIPE CONNECTION PIPE | 1 | |
| 6 | 504044299 | WATER PIPE WATER PIPE | 1 | |
| 7 | 504067723 | HEXAGON BOLT HEXAGON BOLT | 6 | |
| 8 | 504067722 | HEXAGON BOLT HEXAGON BOLT | 8 | |
| 9 | 17289881 | O-RING O-RING | 2 | |
| 10 | 16673635 | HEXAGON BOLT HEXAGON BOLT | 8 | |
| 11 | 16592424 | HEXAGON BOLT HEXAGON BOLT | 2 | |
| 12 | 16690735 | CYLIND-HEAD SCREW CYLIND-HEAD SCREW | 4 | |
| 13 | 17094824 | WASHER WASHER | 4 | |
| 14 | 504065726 | FLAT ENGINE GKT FLAT ENGINE GKT | 1 | |
| 15 | 504059987 | WATER PIPE WATER PIPE | 1 | |
| 16 | 16673735 | HEXAGON BOLT HEXAGON BOLT | 4 | |
| 17 | 16992315 | THREADED PLUG THREADED PLUG | 2 | |
| 18 | 99489018 | SEAL GASKET SEAL GASKET | 2 |
